MAPLA- Modular energy supply system for load lifting magnets
iMAPLA system description
System overview
Controller with CAN Bus
The controller for the iMAPLA series 2013oers an additional CAN Bus
connection which can be programed according to Standard J1939specic to
the application. It is possible to establish adirect connection to the machine
controller without the MMI.
Once an external MMI is connected to the MMI interface on the controller,
command input via CAN is blocked. Transfer of the status values remains
active.
Ö GTS type designation and identication, page53
Generator
The generator provides the electrical voltage/current needed for an action
to the connected lifting magnet.
There are arange of options for providing drive power to the generator.
Ö Generator drive types, page28
Lifting magnet
The lifting magnet is freely selectable as part of the indicated specications
and performance constraints. The system automatically adapts to the
connected lifting magnet.
Manual control unit
The system is controlled via apushbutton which is connected to the MMI.
This button is xed to any part of the manual control unit in the excavator
cab. Normally, abutton is used in the joystick that is used to control the
excavator.
The manual control unit is freely selectable as part of the indicated
specications.
