Issue 08/2013 Page 152
MAPLA- Modular energy supply system for load lifting magnets
Options and accessories
MMI with radio modem
11.1.5 Installing the radio MMI
The MMI is installed inside the cab within the driver's eld of vision to allow
him/her to monitor the indicated operating states. Either screw on with
4screws or secure with the aid of apermanently magnetised plate axed to
the reverse side.
Note
The radio MMI installed in the driver's cab needs its own power
supply from the on-board power supply which can be switched
o and is protected with afuse. Normally excavators have their
own terminal for such purposes behind the ignition lock- this is
separately fused and is switched via the ignition lock.
The supply voltage is also transmitted in the cable for the control button.
Ö Fig. 36, Connection assignment control button, page150
11.1.6 Installing the radio modem
The radio modem is attached in the vicinity of the switch box in
asuitable position. Either screw on with 4screws or secure with the aid of
apermanently magnetised plate axed to the reverse side.
Note
Choose asuitable installation site for the radio modem to allow
the aerial to receive radio waves unimpeded without their
separation. Apartition can arise e.g.when installing in an engine
compartment with very few openings which is fully surrounded
by metal.
