NOTE:
A quick blinking RUN LED indicates that the card is in the process of startup rather than operating
properly. The ALM LED will be on for a period of time when the system starts up.
SRPU active/standby status LED (ACTIVE)
The SRPUs provide the active/standby status LED (ACTIVE) to indicate the status—active or standby—of
the SRPUs.
Table 59 SRPU active/standby status LED description
LED LED status Description
On The SRPU is active.
ACTIVE
Off
This status occurs in the following cases:
• The SRPU is in standby status.
• The SRPU is faulty. Check the card LED
to confirm the problem.
CF card status LED (CFS)
The SRPUs provide a CF card status LED (CFS) to indicate the status of the CF card.
Table 60 CF card status LED description
LED LED status Description
On The CF card is in position.
CFS
Off
The CF card is not in position or is
damaged.
RJ-45 Ethernet interface status LED
The SRPUs provide RJ-45 Ethernet interface status LEDs to indicate the link status and data
receiving/forwarding status of the corresponding Ethernet interfaces.
Table 61 RJ-45 Ethernet interface status LED description
LED LED status Description
Blinking
The Ethernet interface is receiving
or sending data.
On A link is present.
RJ-45 Ethernet interface status LED
Off No link is present.
Combo port status LED
A combo port comprises an SFP interface and an RJ-45 Ethernet interface. Only one interface of a
combo port can work at a time. The SRPUs provide a combo port status LED to indicate the link status and
data receiving/forwarding status of the corresponding combo port.
