Hardi ALPHA EVO II EcoDrive User Manual

7 - Repair
197
SPN Component / Location Description (Error location) FMI
651 Single injector Short circuit (injector 1) 3, 4, 11, 13
651 Single injector Cable break (injector 1) 5, 13
652 Single injector Short circuit (injector 2) 3, 4, 11, 13
652 Single injector Cable break (injector 2) 5, 13
653 Single injector Short circuit (injector 3) 3, 4, 11, 13
653 Single injector Cable break (injector 3) 5, 13
654 Single injector Short circuit (injector 4) 3, 4, 11, 13
654 Single injector Cable break (injector 4) 5, 13
655 Single injector Short circuit (injector 5) 3, 4, 11, 13
655 Single injector Cable break (injector 5) 5, 13
656 Single injector Short circuit (injector 6) 3, 4, 11, 13
656 Single injector Cable break (injector 6) 5, 13
657 Single injector Short circuit (injector 7) 3, 4, 11, 13
657 Single injector Cable break (injector 7) 5, 13
658 Single injector Short circuit (injector 8) 3, 4, 11, 13
658 Single injector Cable break (injector 8) 5, 13
676 Air heater relay Cable break or wrong connection 4, 11
676 Air heater relay Inoperable during shut-off 2, 5, 11
677 Start relay Start relay (high side): Short circuit 3, 4, 11
677 Start relay Start relay (low side): Cable break or short circuit, disabled by ECU 3, 4, 5, 11
701 Reserve output Short circuit to Ubatt (output 1) 11
701 Reserve output Short circuit to ground (output 1) 11
701 Reserve output Cable break or ECU internal error (output 1) 11
702 Reserve output Short circuit to Ubatt (output 2) 11
702 Reserve output Short circuit to ground (output 2) 11
702 Reserve output Cable break or ECU internal error (output 2) 11
703 Engine operating signal lamp Cable break or ECU internal error 2, 3, 4, 5
704 Coolant temperature warning lamp Cable break or short circuit 11
705 Oil pressure warning lamp Cable break or short circuit 2, 3, 4, 5
729 Air heater relay Cable break or short circuit 3, 4, 5, 11
730 Air heater magnetic valve Cable break or short circuit 3, 4, 5, 11
898 CAN message Missing (message “TSC1-TE”) 11, 12
923 Engine power output Engine power output: Cable break or short circuit 2, 3, 4, 5
975 Fan actuator Fan actuator: Cable break or short circuit 2, 3, 4, 5
1072 Engine break (internal) Internal engine brake: Cable break or short circuit 3, 4, 5, 11
1074 Engine break flap actuator Engine brake flap actuator: Cable break or short circuit 3, 4, 5, 11
1079 ECU internal error Wrong voltage of internal 5V reference source 1 3, 4, 11
1080 ECU internal error Wrong voltage of internal 5V reference source 2 3, 4, 11
1081 Preheating signal lamp Cable break or short circuit 2, 3, 4, 5
1109 Shut-off request Shut-off request ignored by operator 2, 11
1231 CAN bus off-state Cable break or short circuit, off-state (CAN bus B) 11, 14
1235 CAN bus off-state Cable break or short circuit, off-state (CAN bus C) 11, 14
1237 Override switch Switch hangs 2, 11
