Hardi ALPHA EVO II EcoDrive User Manual

7 - Repair
198
SPN Component / Location Description (Error location) FMI
1322 Multiple cylinders Misfire detected 11,12
1323 Single cylinder Misfire detected (cylinder 1) 11, 12
1324 Single cylinder Misfire detected (cylinder 2) 11, 12
1325 Single cylinder Misfire detected (cylinder 3) 11, 12
1326 Single cylinder Misfire detected (cylinder 4) 11, 12
1327 Single cylinder Misfire detected (cylinder 5) 11, 12
1328 Single cylinder Misfire detected (cylinder 6) 11, 12
1346 Misfire Misfire detected with system reaction 0, 11
1450 Single cylinder Misfire detected (cylinder 7) 11, 12
1451 Single cylinder Misfire detected (cylinder 8) 11, 12
1638 Customer-specific sensor Cable break or short circuit (sensor 2) 3, 4, 11, 12
1638 Customer-specific temperature Outside target range with system reaction (temperature 2) 2, 11
2634 Main relay Short circuit to Ubatt (relay 1) 3, 11
2634 Main relay Short circuit to ground (relay 1) 4, 11
2634 Main relay Short circuit to ground or emergency shut-off (relay 2) 7, 11, 12
2634 Main relay Short circuit to ground or emergency shut-off (relay 3) 7, 11, 12
2791 EGR actuator (external) Short circuit to Ubatt 3, 11
2791 EGR actuator (external) Short circuit to ground 4, 11
2791 EGR actuator (external) Cable break or ECU internal error 2, 5, 11
2791 EGR actuator (external) Cable break or short circuit 2, 3, 4, 5
523212 CAN message Missing (message”EngPrt” = engine protection) 11, 12
523216 CAN message Missing (message “PrHtEnCmd” = Preheat and engine command 11, 12
523218 CAN message Missing (message “RxCCVS” = cruise control) 11, 12
523222 CAN message Missing (message “TCO1” = speedo signal) 11, 12
523238 CAN message Missing (message “SwtOut” = switch outputs) 11, 12
523239 CAN message Missing or value abote target range (message “DecV1” = pseudo pedal) 2, 12
523240 CAN message Missing (message “FunModCtl” = function mode control) 11, 12
523350 Multiple injectors Short circuit (cylinder bank 1) 3, 4, 11, 13
523351 Multiple injectors Cable break (cylinder bank 1) 5, 13
523352 Multiple injectors Short circuit (cylinder bank 2) 3, 4, 11, 13
523353 Multiple injectors Cable break (cylinder bank 2) 5, 13
523354 ECU internal error Injector power stage A 2, 3, 12, 14
523355 ECU internal error Injector power stage B 12
523370 Rail pressure Compression test active: Rail-pressure monitoring is going to be disabled 11, 14
523420 ECU internal error Watchdog counter exceeds maximum 11, 14
523450 Multi state switch Cable break or short circuit, input voltage outside target range (switch 1) 2, 3, 4, 11
523451 Multi state switch Cable break or short circuit, input voltage outside target range (switch 2) 2, 3, 4, 11
523452 Multi state switch Cable break or short circuit, input voltage outside target range (switch 3) 2, 3, 4, 11
523470 Rail pressure limiting valve Opening failure 2, 11, 12, 14
523470 Rail pressure limiting valve Opening failure with system reaction 11, 12
523490 ECU internal error Redundant shut-off conditions detected 3, 4, 11, 12
523500 CAN message Time-out of at least one sended message 11, 12
