Hardi ALPHA EVO II EcoDrive User Manual

7 - Repair
199
SPN Component / Location Description (Error location) FMI
523550 Terminal 50 Engine start switch hangs 11, 12
523550 ECU internal error Time processing unit (TPU) defective 2, 11
523561 Begin of injection period Outside target range or missing (cylinder 1) 2
523562 Begin of injection period Outside target range or missing (cylinder 2) 2
523563 Begin of injection period Outside target range or missing (cylinder 3) 2
523564 Begin of injection period Outside target range or missing (cylinder 4) 2
523565 Begin of injection period Outside target range or missing (cylinder 5) 2
523566 Begin of injection period Outside target range or missing (cylinder 6) 2
523567 Begin of injection period Outside target range or missing (cylinder 7) 2
523568 Begin of injection period Outside target range or missing (cylinder 8) 2
523600 ECU internal error Serial communication interface defective 11, 12
523601 ECU internal error Wrong voltage of internal 5V reference source 3 3, 4, 11
523602 Fan speed Aove target range with system reaction 2, 11
523604 CAN message Missing (message “RxEngTemp” = engine temperature) 11, 12
523605 CAN message Missing (message “TSC1-AE”) 11, 12
523606 CAN message Missing (message “TSC1-AR”) 11, 12
523607 CAN message Missing (message “TSC1-DE”) 11, 12
523608 CAN message Missing (message “TSC1-DR”) 11, 12
523609 CAN message Missing (message “TSC1-PE”) 11, 12
523610 CAN message Missing (message “TSC1-VE”) 11, 12
523611 CAN message Missing (message “TSC1-VR”) 11, 12
523612 ECU internal hardware monitoring A recovery occured which is stored as protected 11, 14
523612 ECU internal hardware monitoring A recovery occured which is not stored 11, 14
523612 ECU internal hardware monitoring A recovery occured which is visible in the error memory 11, 14
523612 ECU internal hardware monitoring Overvoltage 3, 11
523612 ECU internal hardware monitoring Undervoltage 4, 11
523613 Rail pressure Positive deviation (speed dependent) outside target range 0, 11
523613 Rail pressure Positive deviation (flow dependent) outside target range ( => Leakage!) 0 , 11
523613 Rail pressure Negative deviation (flow dependent) outside target range 0, 11
523613 Rail pressure Negative deviation (speed dependent) outside target range 1, 11
523613 Rail pressure Pressure above target range 0, 11
523613 Rail pressure Implausible (leakage, injector needle blocked in open position) 2, 11
523615 Metering unit valve Flow rate outside target range 3, 4, 11
523615 Metering unit valve Not connected or output disabled 5, 11, 12
523615 Metering unit valve Short circuit to Ubatt 11, 12
523615 Metering unit valve Short circuit to ground 11, 12
523617 ECU internal error Communication with chip CJ940 disturbed 11, 12
- Customer-specific sensor Cable break or short circuit (sensor 1) 2, 3, 4, 11
- Customer specific temperature Outside target range with system reaction (tempereature 1) 2, 11
