Modules and transducers
QuantumX A03031_24_E00_01 HBM: public 101
This function delivers the best results when the ambient temperature of the
MX1609/KB/TB, and therefore the temperature of the cold junction, is kept
constant.
Conditions for using RFID chips for measuring point identification:
S All channels can read/write via RFID
S The neighboring channel must not be occupied in the MX1609/KB/TB dur
ing writing
S Maximum distance chip to housing: 1 mm
S For self-assembly: Check position of chip on plug
Thermocouple plug with integrated RFID chip from HBM
RFID chip
The chip for measuring point identification is already integrated in the HBM
THERMO-MINI.
