Mechanical
40 A03031_24_E00_01 HBM: public QuantumX
6.1 Mounting case clips on modules
The module electronics are integrated in a metal housing that is surrounded by
a case protection (CASEPROT). This also serves for centering when several
devices are stacked on top of each other and offers a certain degree of protec
tion against mechanical damage.
MX840 housing
Case protection
Cover
Fig. 6.1 Amplifier MX840 with case protection
The mounting of the housing clips shown in the following pictures must be
implemented on both sides of the housing.
