HBM QuantumX - Quarter Bridge, Resistive

Transducer connection
QuantumX A03031_24_E00_01 HBM: public 123
9.6 Quarter bridge, resistive
Measuring amplifier directly supporting resistive quarter bridges:
MX1615B/MX1616B.
Quarter bridges can be connected via an adapter to: MX840B, MX440B,
MX430B and MX410B. For connecting individual SGs to this adapter see the
following page.
Hsg. = Housing
2 Data
3 No function
1
4
7
1
123
1-wire EEPROM (optional)
view from below
Four-wire circuitThree-wire connection
8
Cable shield
5
6
SG
SG
bk
gy
gn
ye
bu
MX1615B/MX1616B
1
8
Push in
Cable color code:
wh= white;
bk= black;
bu= blue; rd= red;
ye = yellow;
gn= green;
gy= gray
Complementary quarter bridge:
MX1615B: 120 and 350 Ohm
MX1616B: 350 and 1000 Ohm
