Introduction
QuantumX A03031_24_E00_01 HBM: public 21
S Up-to date versions are always available from our Internet site at www.hb
m.com/hbmdoc
4.2 The QuantumX family
The QuantumX family is a modular measurement system for universal applica
tions. The modules can be individually combined and intelligently connected
according to the measurement task. Distributed operation makes it possible to
position individual modules close to the measuring points, resulting in short
sensor lines.
SomatXR is the ultra-rugged version of the QuantumX modules for acquiring
measurement data even in harsh environments. The two series can be
interconnected at will. For initial operation of your modules we recommend you
visit www.hbm.com/start/.
The QuantumX family consists of the following modules:
S MX840B Universal amplifier
The module has 8 universal inputs and supports more than 15 transducer
technologies.
S MX440B Universal amplifier
Like the MX840B, but with 4 inputs (connections 5-8 of MX840B, without
CAN).
S MX410B Highly dynamic universal amplifier
The module has 4 universal inputs and supports commonly used transducer
technologies (at a sampling rate of up to 96,000 measured values per chan
nel per second).
S MX430B QuantumX precision bridge measurement module. The module
has 4 inputs and supports full bridge SG-based transducers with an accu
racy class of 100 ppm.
S MX238B Precision full bridge amplifier
The module has 2 full bridge SG inputs with an accuracy of 25 ppm.
S MX460B Digital module (counter, frequency, timer)
The module has 4 individually configurable inputs for connecting HBM
torque measurement shafts (T12, T40, T10), rotational speed sensors,
crankshaft sensors with gap (TDC sensor), pulse width modulated signals -
PWM.
