Modules and transducers
QuantumX A03031_24_E00_01 HBM: public 93
CAN LEDs
Green CAN bus activated, CAN data can be received
Orange CAN bus in "WARNING" state, CAN data received but bus is
subject to occasional disruptions; buffer overflow, some data
items lost
Red CAN bus in "ERROR" or "BUS-OFF" state, CAN data cannot
be received or processed
General rule: Brief flashing → TEDS identified (green: is used, orange: is not used).
8.6 MX238B resistive full bridge measuring amplifier
You can connect up to four transducers to the universal amplifier MX238B. The
transducers are connected via 15-pin D-SUB-15HD device connectors. All
measuring channels are electrically isolated from one another and from the
power supply.
MX238B connectable transducers
Transducer type Connection sockets See page
Resistive full bridge 1 ... 2 116
8.6.1 MX238B pin assignment
So that insertion or removal of a transducer connection can be unmistakably
identified, Pin 4 and Pin 9 in the connector plug must be bridged! If this bridge
is missing, no measurement values will be recorded at the connection!
