Modules and transducers
QuantumX A03031_24_E00_01 HBM: public 103
Red No sensor connected
Channel error (incorrectly parameterized, connection er
ror, invalid TEDS data)
Red Sensor supply overload
General rule: Brief flashing → TEDS identified (green: is used, orange: is not used).
8.9 MX471C CAN FD/CAN module
8.9.1 General information
The MX471C module provides four independent CAN FD/CAN ports that are
all electrically isolated from each other and for power supply. The module
additionally offers 2 Ethernet ports, and can be used as a gateway module
between multiple measurement modules and the PC.
Connectable MX471C buses
Type
Connector sockets /
nodes
See
page
CAN FD/CAN/CAN raw /xCP-on-CAN 1 ... 4 154
Connected devices are not directly addressed during data transmission on a
CAN bus. A unique identifier denotes the contents of a message (e.g. rota
tional speed or engine temperature).
The identifier also signifies the priority of the message.
Message = identifier + signal + additional information
Device connected to the bus = node
Each node on the MX471C can be parameterized as a receiver and/or a
transmitter/gateway. Parameterization as a receiver is described in
section 8.9.4. Parameterization as a transmitter is set out in section 9. The
online help that comes with the respective software package provides detailed
information about parameterization.
