4 Introduction
4.1 About the QuantumX documentation
The QuantumX family documentation consists of
S a printed quick-start guide for initial startup and safety instructions
S the data sheets in PDF format
S This operating manual in PDF format
S the operating manual for the EtherCAT®
ℑ
1)
/ PROFINET / Ethernet gate
ways CX27C in PDF format
S the operating manual for data recorder CX22B-W and CX22B data
recorders
S the operating manual for the MX403B and MX809B modules for safe
measurement at high electric potential
S the MXFS BraggMETER optical module operating manual
S the operating instructions for the Signal Conditioning Modules (SCM)
- High-voltage signal conditioned SCM-HV (300 V CAT II)
- Quarter bridge adapter SCM-SG-120 / -350 / -1000 for connecting SGs
individually
S the product descriptions for accessories
S a comprehensive online help with index and easy search options which is
available after the installation of a software package (e.g. MX Assistant,
catman®Easy/AP). Information about module and channel configuration
can also be found here.
These documents can be found
S From the starter website www.hbm.com/start/ in the "System software and
documentation" package
S After installation of the MX Assistant on the hard drive of your PC, which
can be reached through the Windows start menu
1)
EtherCAT® is a registered brand and patented technology, licensed by Beckhoff Automation
GmbH, Germany
