Modules and transducers
90 A03031_24_E00_01 HBM: public QuantumX
Red Sensor supply overload
Analog output LEDs
Green Error-free operation
Orange System is not ready, boot procedure running
Red
Orange
Red
Overcurrent at the analog output
Input signal overflow
Overflow due to invalid scaling of the analog outputs
General rule: Brief flashing → TEDS identified (green: is used, orange: is not used).
8.5 MX430B resistive full bridge measuring amplifier
You can connect up to four transducers to the universal amplifier MX430B. The
transducers are connected via 15-pin D-SUB-15HD device connectors. All
measuring channels are electrically isolated from one another and from the
power supply.
MX430B connectable transducers
Transducer type Connection sockets See page
Resistive full bridge 1 ... 4 116
