6.4.4 BPX003 backplane
85
271
Fig. 6.15 BPX003 backplane
6.4.5 Mounting the modules
Tools
We recommend a T-handle Allen wrench 4x150 (4 mm across
flats, length 150 mm).
Notice
The modules can only be fastened in backplanes in housings with degree of
protection IP20 without case protection, case clips or lateral covers. If these
are present, remove as shown in section 6.
