HBM QuantumX - Frequency, Single-Pole, Without Directional Signal

Transducer connection
QuantumX A03031_24_E00_01 HBM: public 143
9.23 Frequency, single-pole, without directional signal
Supported by the following modules: MX840B, MX440B, MX460B
9
4
Hsg.
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye = yellow; gn= green; gy= gray
10
Ground
Plug 1
Md
Cable shield
f
1
(+)
5
1
4
rd
wh
gy
5
6
5 V
3.5 V
1.5 V
Thresholds
Thresholds
f
1
Signal single-pole, schematic diagram
0 V
Hsg. = Housing
HBM torque transducer
6
1
123
1
5
6
10
11
15
2 Data
3 No function
1
Adjustable sensor supply: Pin12: 5 V ... 24 V
Pin 11: 0 V
1-wire EEPROM (optional)
view from below
15
Shunt calibration
Maximum input voltage: 5 V to ground
NOTE
