HBM QuantumX - Half Bridge, Resistive

Transducer connection
120 A03031_24_E00_01 HBM: public QuantumX
9.4 Half bridge, resistive
Supported by the following modules: MX840B, MX440B, MX410B, MX1615B
8
7
4
9
Hsg.
2
3
5
Cable color code: wh= white; bk= black; bu= blue; rd= red; ye= yellow; gn= green; gy= gray
wh
bk
bu
gn
gy
ye
Measurement signal (+)
Excitation (+)
Sense lead (-)
Sense lead (+)
Excitation (-)
Cable shield
Hsg. = Housing
1
5
6
10
11
15
6
1
123
2 Data
3 No function
1
1-wire EEPROM (optional)
view from below
6
4
2
7
8
3
5
1
MX1615B
1
8
Push in
