HBM QuantumX - LVDT Transducers

Transducer connection
QuantumX A03031_24_E00_01 HBM: public 127
9.10 LVDT transducers
Supported by the following modules: MX840B, MX440A
8
7
4
9
Hsg.
2
10
5
Measurement signal (+)
Sense lead (-)
Sense lead (+)
Excitation (-)
Cable shield
Measurement signal (-)
LVDT transducers
Excitation (+)
3
Hsg. = Housing
6
1
123
1
5
6
10
11
15
2 Data
3 No function
1
1-wire EEPROM (optional)
view from below
