Mechanical
QuantumX A03031_24_E00_01 HBM: public 49
S Depending on the installation situation, sufficient ventilation (vertical air
flow) or cooling must be provided (the maximum total output on a backplane
is approx. 150 watts)
S The ventilation slots of the modules must not be covered (by cable ducts,
etc.)
6.4.3 Backplane BPX002
470
462
214.5
448.5
220.9
32.75
65.5
98.25
131
165.3
0
146.05
482.6
Fig. 6.14 Rackmontage BPX002
To use the BMX002 backplane as a desktop enclosure, the 1-BPX002-SIDE
accessory can be used.
