Modules and transducers
86 A03031_24_E00_01 HBM: public QuantumX
All LEDs are flashing orange Firmware download active (system is not ready)
Orange Connection newly assigned, transducer identification
running (calibration)
Green Error-free operation
Flashing green (5s), then
green
TEDS data being read in
Flashing orange (5 s), then
green
Manual configuration ongoing (ignore TEDS)
Red No sensor connected
Channel error (incorrectly parameterized, connection
error, invalid TEDS data)
General rule: Brief flashing → TEDS identified (green: is used, orange: is not used).
8.4 MX410B highly dynamic universal amplifier
You can connect up to four transducers to the highly dynamic universal ampli
fier MX410B. The transducers are connected via 15-pin D-SUB-15HD device
connectors. You will need BNC adapters (accessory 1-IEPEMX410) to connect
the IEPE transducers.
All measuring channels are electrically isolated from one another and from the
power supply. When using the adjustable transducer excitation, electrical isola
tion from the supply voltage of the amplifier is not required.
MX410B connectable transducers
Transducer type Connection sockets See page
Resistive full bridge 1 ... 4 116
Resistive half bridge 1 ... 4 120
Resistive quarter bridge via
adapter
1 ... 4 123
