6 Mechanical
QuantumX modules are extensively tested. This includes
S the expanded temperature range from -20 °C ... +65 °C
S mechanical vibration with an amplitude of 50 m/s² in the frequency range
5 … 2000 Hz in all 3 axes for 2 hours, and
S the effect of exposure to 1000-fold mechanical shock with an acceleration
(half cosine) of 350 m/s² for 3 ms in all 3 axes.
Any deviations from this can be found in the current data sheet for the
respective module.
The degree of protection given in the technical data indicates the suitability of
the housings for various ambient conditions and also the protection of persons
against potential risks when used. The letters IP (International Protection),
which are always present in the designation, are followed by two digits. These
indicate which degree of protection a housing offers against contact or foreign
bodies (first digit) and moisture (second digit).
QuantumX modules are in a housing with IP20 as degree of protection.
IP 2 0
Code
index
Degree of protection against
contact and foreign bodies
Code
index
Degree of protection against
water
2 Protection against contact with
fingers, protection against
foreign substances with ∅
>12 mm
0 No water protection
Both housing types can be connected together with the aid of two lateral hous
ing clips (1-CASECLIP, not included in scope of delivery). To do this, the exist
ing lateral covers must be removed and the housing clips screwed on.
