96 A03031_24_E00_01 HBM: public QuantumX
Green CAN bus activated, CAN data can be received
Orange CAN bus in "WARNING" state, CAN data received but bus is
subject to occasional disruptions; buffer overflow, some data
items lost
Red CAN bus in "ERROR" or "BUS-OFF" state, CAN data cannot
be received or processed
General rule: Brief flashing → TEDS identified (green: is used, orange: is not used).
8.7 MX460B frequency amplifier
You can connect up to four transducers to the frequency measuring amplifier
MX460B. The transducers are connected via 15-pin D-SUB-15HD device con
nectors. All measuring channels are electrically isolated from one another and
from the power supply. When using the adjustable transducer excitation, elec
trical isolation from the supply voltage of the amplifier is not required.
MX460B connectable transducers
Transducer type Connection sockets See page
Torque/speed (HBM torque
transducer)
1 ... 4 142, 151
Frequency measurement, pulse
counting
1 ... 4 from 141
Pulse width, pulse duration,
period duration (PWM)
1 ... 4 153
Inductive rotary encoders 1 ... 4 150
Incremental encoders (1-track,
2-track, index)
1 ... 4 from 141
