Transducer connection
QuantumX A03031_24_E00_01 HBM: public 121
2
RC
Shunt signal only available if 1 and 4 externally connected
Half bridge with shunt
RC
RC
RC
RC
RB
RB
2'
1
3'
3
4
2
Rshunt+
-UB/2
+UB/2
Measurement signal (+)
1)
1)
5 x Cable Resistance
Half bridge
Measurement signal (-)
