Introduction
22 A03031_24_E00_01 HBM: public QuantumX
S MX471C CAN/CANFD module
The module has 4 CAN/CAN FD nodes that can be configured to receive
(raw and PC-based or on-module decoding) or transmit
CAN messages (analog measurement channels). The module also supports
the CCP and xCP-on-CAN/FD protocols on up to 2 channels. The module
can be used as a gateway.
S MX1601B Analog amplifier (standardized voltage / current, IEPE)
The module has 16 individually configurable inputs for standardized voltage
or current measurement or for connecting current-fed piezoelectric trans
ducers (IEPE / ICP(R) ).
S MX1615B/MX1616B SG bridge amplifier
The module has 16 individually configurable inputs for SGs in quarter, half
and full bridge circuits. Bridge excitation voltage DC or carrier frequency.
S MX1609KB Thermocouple amplifier
The module has 16 inputs for type K thermocouples.
S MX1609TB Thermocouple amplifier
The module has 16 inputs for type K thermocouples.
S MX809B Thermo measurement module
The module has 8 inputs for measurement of temperatures with thermocou
ples or electrical cell voltages up to 5 V at a potential up to 1000 V in energy
storage systems. General measurement categories: 600 V CAT II, 300 V
CAT III.
The module and entire production have been certified by VDE, and stand
for maximum safety when working with dangerous voltages.
S MX403B voltage module
The module has 4 inputs with lab connectors for voltage measurement
(1000 V CAT II, 600 V CAT III).
The module and entire production have been certified by VDE, and stand
for maximum safety when working with dangerous voltages.
Notice
When using the modules MX403B or MX809B, please refer to the separate
operating manual, document number A 3757.
