HBM QuantumX - Temperature Transducers

Transducer connection
136 A03031_24_E00_01 HBM: public QuantumX
9.18 Ohmic resistance (e.g. PTC, NTC, KTY, …)
Supported by the following modules: MX840B, MX440B, MX1615B
Hsg.
Cable shield
Four-wire circuit
10
4
9
1)
When connecting a two-wire sensor, wire
bridges must be soldered in the connector
(between measurement line and supply)
2
5
1)
3
Hsg. = Housing
6
1
123
1
5
6
10
11
15
2 Data
3 No function
1
1-wire EEPROM (optional)
view from below
4
5
8
6
7
1
MX1615B
1
8
Push in
