Real-time functions and outputs
QuantumX A03031_24_E00_01 HBM: public 167
The logic output can be assigned to a digital output. Parameterization includes
the input signal and, in addition, the switching threshold, hysteresis, switching
logic and output logic.
The update rate of limit values is 4800 Hz.
Switching on
Switching level
Hysteresis value
Switching level
Switching on
Switch off
Switch off
Over limit
Under limit
Hysteresis value
24 V
0 V
24 V
0 V
LV1
LV2
LV1 logic 1
LV2 logic 1
Fig. 10.4 Limit value functions and parameters
Examples of connections for MX879B
Digital output 24 V (1)
24 V
GND
1 … 32
2
3
4
U
INT
24 V
Ground
I/O
1
2
3
4
5
6
7
8
