Supervisormode
140 A4774-1.0 HBM: public WTX110
Coarse flow
Fine flow
Coarse flow cut-
off point
Start
Fine flow cut-off
point
Time
Time
Off
Off
On
On
First fine flow phase
before coarse flow
Fig. 10.4 Fill cycle with Coarse/Fine valve control with first fine flow phase activated
(see also section 10.2.26)
