Installation
WTX110 A4774-1.0 HBM: public 35
4.7 USB connection
If a WTX110 is ordered with a USB connection, the USB connection is
completely pre-wired. Devices can be connected via USB connector socket
type A on the bottom of the device.
4.8 Ethernet TCP/IP connection
If a WTX110 is ordered with an Ethernet connection, the Ethernet connection
is completely pre-wired. Devices can be connected via M-12 socket on the
bottom of the device.
An HBM connection cable can be used for the connection to local 10/100-Mbit
Ethernet networks.
S 1-KAB2129-5: Ethernet connection cable M12 plug to RJ45 plug (straight)
(5 m)
S 1-KAB2130-5: Ethernet connection cable M12 plug (90°) to RJ45 plug (5 m)
S 1-KAB2129-10: Ethernet connection cable M12 plug to RJ45 plug (straight)
(10 m)
S 1-KAB2130-10: Ethernet connection cable M12 plug (90°) to RJ45 plug
(10 m)
Information
Cable length without repeater (hub/switch) max. 80 m
