Installation
36 A4774-1.0 HBM: public WTX110
4.9 Digital inputs/outputs
Depending on the configuration of the relevant variant, the WTX110 has a
maximum of three digital inputs and four digital outputs on the device. It is also
possible to connect up to four digital inputs and 4 digital outputs via a Modus/
TCP fieldbus coupler (for example Wago 750-342). See chapter 4.9.2.
There are two independent options available for digital I/Os, (1) IO and / or (2)
DIO
K-WTX110-*-***-**-***-IO-***-**
2x DO and 2 x DI
Information
If the IO option is selected, no additional interfaces can be used on this option!
K-WTX110-*-***-**-DIO-** -***-**
2 x DO and 1 x DI
Information
If the DIO option is selected, no additional interfaces can be used on this
option!
In the maximum configuration level no additional options such as Ethernet
TCP/IP, USB or an analog output are possible.
If a WTX110 is ordered with option "IO" and / or "DIO", the interface is
completely pre-wired. The IO option is always used in slot PIM1, DIO always in
SIM1.
