Installation
WTX110 A4774-1.0 HBM: public 37
4.9.1 Overview I/O Connection
Settings at the WTX110 Config 1 Config. 2 Config. 3
Group 1
(Config.->Digital I/O)
SIO
see
Tab. 4.2
PIM
see
Tab. 4.1
PIM
see
Tab. 4.1
Group 2
(Config.->Digital I/O)
SIO
see
Tab. 4.2
Number of outputs 2 2 4
Number of inputs 1 2 3
Overview of terminalblocks
Output 1 KL2-OUT0 KL3-OUT0 KL3-OUT0
Output 2 KL2-OUT1 KL3-OUT1 KL3-OUT1
Output 3 na na KL2-OUT0
Output 4 na na KL2-OUT1
Input 1 KL2-IN0 KL3-IN0 KL3-IN0
Input 2 na KL3-IN1 KL3-IN1
Input 3 na na KL2-IN0
Input 4 na na na
