Installation
38 A4774-1.0 HBM: public WTX110
4.9.2 Overview I/O Connection with Ethernet (Modbus-TCP) Fieldbus
coupler
Settings at the WTX110 Config 4 Config. 5
Group 1
(Config.->Digital I/O)
PIM Modbus/TCP
Group 2
(Config.->Digital I/O)
Modbus/TCP -
Number of outputs 4* 4*
Number of inputs 4* 4*
Overview of terminalblocks
Output 1 KL2-OUT0 MTCP-Output 1
Output 2 KL2-OUT1 MTCP-Output 2
Output 3 MTCP-Output 1 MTCP-Output 3
Output 4 MTCP-Output 2 MTCP-Output 4
Input 1 KL3-IN0 MTCP-Input 1
Input 2 KL3-IN1 MTCP-Input 2
Input 3 MTCP-Input 1 MTCP-Input 3
Input 4 MTCP-Input 2 MTCP-Input 4
