Calibration
WTX110 A4774-1.0 HBM: public 159
11 Calibration
To access the Calibration group select the following keys:
Menu Key Function
Standard Switch from Standard to version notice
WTX110V#.# Display the current firmware version number
Call password entry within 3 seconds
Password 324 Enter the password
1 Service mode Call Service mode
Service: Interface Press twice to switch to the Calibration group
options
Service: Calibration
11.1 Multiple-range
The A/D converter can be configured as a single, dual or triple-range scale.
The individual ranges differ in their maximum load and scale interval.
Example of three-range scale with a resolution of 3000 increments in each
weighing range:
Lowest weighing range: 0 to 1500kg / 0.5 kg
Middle weighing range: 0 to 3000kg / 1.0 kg
Highest weighing range: 0 to 6000kg / 2.0 kg
