HBM WTX110 - Configuration Options; Configure Scale

Service mode
78 A4774-1.0 HBM: public WTX110
6.2.1 Continuous Out
→ HBM Remote selected
Cont. Out: Eth Eth Protocol via Ethernet port (on underside of
device)
SIM1 Protocol via serial interface
Cont. Out port: 1900 TCP/IP port via which the external connection is
made. Only with Cont. Out: Eth
Cont: Out rate: 5 Enter the number of updates of the continuous
output per second
→Customized selected
Cont. Out: Eth Eth Protocol via Ethernet port (on underside of
device)
SIM1 Protocol via serial interface
Cont. Out port: 1900 TCP/IP port via which the external connection is
made. Only with Cont. Out: Eth
