Calibration
176 A4774-1.0 HBM: public WTX110
→ After displaying the last linearization point, or if there are no points
New Fixpoint 1? N Y Enter linearization point
N Do not enter linearization point; back to
Select Group
Enter Fixpt.1 999999 Enter the weight to be linearized
Calibrate Fixpt? N Y Calibrate linearization point
N Enter linearization value
→ With Calibrate Fixpt = Y
Linearization.. Measurement of the linearization signal
Menu Key Function/Secondary selection
Weight: 9999999 Display the linearized weight value with 10 times
higher resolution (as a check)
Lin.Signal1 0.50000 Enter a calculated linearization signal or import
the values from another A/D converter
Continue in New Fixpoint 2? step
A new linearization point can be inserted between existing points. Then all the
points are renumbered in ascending order.
11.7 Zero Adjust
For more information on the keys necessary to access this menu group, go to
the Navigation Pilot.
In this menu group the zero point of the scale can be redefined. This becomes
necessary in particular when the scale has been calibrated using an auxiliary
frame. After removing the auxiliary frame, the final zero point is then defined.
The change in zero point shifts the weighing range accordingly.
