System description
WTX110 A4774-1.0 HBM: public 17
3 System description
The WTX110 weighing terminal is designed for universal use, for example in
weighing, recording and dosing systems.
Depending on the device variant, either analog SG load cells or specified digital
HBM sensors and electronics can be used.
Depending on the device variant, three power supplies are available
S 12 … 30 VDC
S 110 … 240 VAC
S External battery 12 … 30VDC (battery not included)
Two stainless steel housing variants (1) table / wall-mounting or panel
mounting are available. Both variants have IP protection rating IP69K (panel-
frame: front).
Fig. 3.1 Desktop and wall mounting
