Operating modes
WTX110 A4774-1.0 HBM: public 93
7.2 Operating mode FILLER
The FILLER operating mode provides all the basic functions for implementing
filling and dosing control with coarse/fine flow. All settings such as target
weight and cut-off points for coarse/fine flow can be made in Supervisor Mode
or via PanelX. Up to 32 parameter sets can be created for various products.
Select product
Product-No. 1
OK
Enter project number
WTX110 V#.#.#
Return
<3s
>3s
Supervisor mode
Setup
Make settings for the products
(target weight, coarse flow,
fine flow, etc.)
See section 10.2
Select product
1 Name
OK
Ready to start
Return
Fig. 7.2 Configure FILLER and select product
