Operating modes
94 A4774-1.0 HBM: public WTX110
Select product
Product-No. 1
OK
Enter project number
Return
Display of target weight,
number, total, mean value,
standard deviation
Select product
1 Name
OK
Ready to start
ReturnInfo
Coarse …
Start
Filling process runs
automatically …
Record weight*
Weigh
Enter the current weight in alibi
memory and send output to
printer/PC
* Weight recording must be activated
under Service/Application
Fig. 7.3 Control filling process and weight recording
