Calibration
WTX110 A4774-1.0 HBM: public 165
When setting the jumper, take care to ensure it is set on both pins to ensure
reliable calibration.
The position of the W1 jumper can be locked by a
weights and measures officer with thread and lead or a
seal: A description of calibration can be found in section
11 "Calibration," page 159!
In legal for trade applications, the covering and lid must be sealed by adhesive
labels so that the position of the calibration switch can no longer be changed.
→ If switch W1 saved in calibration data position
Calibration locked Switch W1 not in calibration position, parameters
cannot be saved!
Access calibration without save option (e.g. for
checking)
