Service mode
72 A4774-1.0 HBM: public WTX110
Function/Secondary selectionKeyMenu
Com1: Data bits 8 Select the data format of the Com1 interface1:
7 7 data bits
8 8 data bits
1 stop bit is always transferred.
Com1: Parity None Select the parity for the Com1 interface:
None No parity
Even Even parity
Odd Odd parity
COM1: Contrl. None Select the send/receive control
(hardware handshake) of the Com1 interface:
XOn/Xoff Control by XON/XOFF
RTS/CTS Control with RTS/CTS
None No flow control
Notice: RTS/CTS not possible on Com2!
Com1: Protcl. None Select the transfer protocol of Com1:
None Raw data only
TTY Printer control (data only)
AckNak Secure procedure with
acknowledgment
NoAck Secure procedure with
acknowledgment
→Protocol TTY selected
Com0: Codepage None Output character set:
None ISO8869 as per selected language
850 DOS code page 'Western Europe' for
older printers
852 DOS code page 'Central Europe'
866 DOS code page 'Russian'
Star DOS code page Star printer
