Service mode
82 A4774-1.0 HBM: public WTX110
Menu Key Function/Secondary selection
Config. Analog out
AOut 1: DAU15 DAU15 Internal analog output 15-bit
None Not assigned
Notice: If the device variant has an analog output,
DAU15 must always be selected!
Aout1: Mode Select operating mode:
0-10 V, 2-10 V, 0-20 mA, 4-20 mA
→ Gross or Net selected
AOut 1: Scale 1 Selection of scale for output of gross/net weight
AOut 1:Calibration N Fine adjustment of the minimum and maximum
output signal:
N No fine adjustment
Y Fine adjustment using a multimeter
→ Perform calibration
AOut 1: 0V = 9 Calibrate zero point, for example =0V, change
analog signal incrementally
AOut 1: 10V = 4095 Calibrate full load value, for example =10V,
change analog signal incrementally
