Network Video Recorder User Manual
25
STATUS
Turns blue when device is controlled by an IR
remote.
HDD
Turns red when controlled by a keyboard and
purple when IR remote and keyboard is used
at the same time.
MODEM
(not for
DS-9600NI-XT)
Flashes red when data is being read from or
written to HDD.
TX/RX
Reserved for future usage.
GUARD
Flashes blue when network connection is
functioning properly.
2
IR Receiver
Receiver for IR remote
3
DVD-R/W
Slot for DVD-R/W disk.
4
Alphanumeric Buttons
Switch to the corresponding channel in live
view or PTZ control mode.
Input numbers and characters in edit mode.
Switch between different channels in playback
mode.
The light of the button is blue when the
corresponding channel is recording; it is red
when the channel is in network transmission
status; it is pink when the channel is recording
and transmitting.
5
USB Interfaces
Universal Serial Bus (USB) ports for additional
devices such as USB mouse and USB Hard Disk
Drive (HDD).
6
Composite
Keys
ESC
Back to the previous menu.
Press for arming/disarming the device in Live
View mode.
REC/SHOT
Enter the Manual Record setting menu.
