5.2 General Specifications
137
Display Specifications
External interface specifications
Accessory and Option Specifications
Display 7-segment LED
Number of display
parameters
4 (display area a, b, c, and d)
Display resolution Other than integrated values: 99999 count (5 digits)
Integrated values: 999999 count (6 digits)
Display update rate 200 ms ±50 ms (approx. 5 updates per sec.) to 20 s (varies with number of averaging
iterations setting)
LAN interface (standard equipment)
Connector RJ-45 connector × 1
Electrical specifications Compliant with IEEE802.3
Transmission method 10Base-T/ 100Base-TX (automatic detection)
Protocol TCP/ IP
Functions HTTP server (remote operation, firmware updates)
Dedicated ports (command control, data transfer)
Remote control by controller (REMOTE lamp will light up.)
Cancelation of remote operation with LOCAL key (REMOTE lamp will turn off.)
RS-232C interface
(included with the PW3335, PW3335-02, PW3335-03, and PW3335-04, specify at time of order)
Connector D-sub 9-pin connector × 1
Communication method Full duplex, Start-stop synchronization
Stop bits: 1 (fixed)
Data length: 8 (fixed)
Parity: None
Remote control by controller (REMOTE lamp will light up.)
Cancelation of remote operation with LOCAL key (REMOTE lamp will turn off.)
Hardware handshake function
Communication speed 9600bps/ 38400bps
GP-IB interface (included with the PW3335-01 and PW3335-04, specify at time of order)
Method Compliant with IEEE488.1 1987, in reference to IEEE488.2 1987
Interface functions: SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, C0
Remote control by controller (REMOTE lamp will light up.)
Cancelation of remote operation with LOCAL key (REMOTE lamp will turn off.)
Address 00 to 30
Accessories
See: "Instrument and accessories" (p.2)
Options
See: "Options (sold separately)" (p.2)
