3.7 Using D/A Output
89
Setting the output parameter, rectifier, and output method for D/A output
channels
1 Press to place the instrument in
the shift state.
2 Press to switch to the D/A output
parameter settings screen. ([
dA] will be
displayed in display area
a.)
3 Press or until the display area
a flashes.
4 Press or to select the D/A
channel you wish to set.
5 Press or until the output
parameter flashes.
6 Press or to select the
parameter you wish to output.
The flashing unit symbol will indicate the parameter
selected for D/A output.
V → A → W → VA → var → PF → ° → VHz
→ AHz → T.AV-A → T.AV-W → Ah+ → Ah-
→ Ah → Wh+ → Wh- → Wh → CF-V →
CF-A → RF-V % → RF-A % → THD-V % →
THD-A % → MCR ⋅⋅⋅
7 Press or until the rectifier
flashes.
8 Press or to change the
rectifier.
Default setting: AC+DC
Settings:
AC+DC → AC+DC Umn → DC → AC
→ FND ⋅⋅⋅
