5.2 General Specifications
136
Input specifications
Basic Specifications
5.2 General Specifications
Measurement line type Single-phase 2-wire(1P2W)
Input methods Voltage Isolated input, resistance voltage division method
Current Isolated input, shunt input method
Isolated input from external current sensors (PW3335-03 or PW3335-04 only)
Input resistance
(50 Hz/60 Hz)
Voltage input terminal: 2 M±0.04 M
Current input terminal: 1 mA to 100 mA range 500 m + 20 m or less
200 mA to 20 A range 5 m + 10 m or less
(at shipment from factory)
For more information about the external current sensors input, see "External Current
Sensor Input Specifications (CURRENT SENSOR)" (p.150).
Voltage measurement
ranges
AUTO/ 6 V/ 15 V/ 30 V/ 60 V/ 150 V/ 300 V/ 600 V/ 1,000 V
Current measurement
ranges
AUTO/ 1 mA/ 2 mA/ 5 mA/ 10 mA/ 20 mA/ 50 mA/ 100 mA/ 200 mA/ 500 mA/ 1 A/ 2 A/
5 A/ 10 A/ 20 A
For more information about external current sensor input, see "External Current Sensor
Input Specifications (CURRENT SENSOR)" (p.150).
Default state: voltage range; 300 V, current range; 20 A, power range; 6 kW, voltage/current auto range; OFF
Constraints: Constraints apply when changing ranges as a result of instrument protection mode.
See "Instrument protection mode" (p.158)
Rated supply voltage 100 V AC to 240 V AC (Voltage fluctuations of ±10% from the rated supply voltage are
taken into account.)
Anticipated transient overvoltage: 2500 V
Rated power supply
frequency
50 Hz/60 Hz
Maximum rated power 30 VA or less
Dimensions Approx. 210W × 100H × 245D mm (8.27”W × 3.94”H × 9.65”D) (excluding protrusions)
Mass Approx. 3 kg (105.8 oz.)
Product warranty period 1 year
Power ranges: Units; W (active power), VA (apparent power), var (reactive power)
Current/ Voltage 6.0000 V 15.000 V 30.000 V 60.000 V 150.00 V 300.00 V 600.00 V 1.0000 kV
1.0000 mA 6.0000 m 15.000 m 30.000 m 60.000 m 150.00 m 300.00 m 600.00 m 1.0000
2.0000 mA 12.000 m 30.000 m 60.000 m 120.00 m 300.00 m 600.00 m 1.2000 2.0000
5.0000 mA 30.000 m 75.000 m 150.00 m 300.00 m 750.00 m 1.5000 3.0000 5.0000
10.000 mA 60.000 m 150.00 m 300.00 m 600.00 m 1.5000 3.0000 6.0000 10.000
20.000 mA 120.00 m 300.00 m 600.00 m 1.2000 3.0000 6.0000 12.000 20.000
50.000 mA 300.00 m 750.00 m 1.5000 3.0000 7.5000 15.000 30.000 50.000
100.00 mA 600.00 m 1.5000 3.0000 6.0000 15.000 30.000 60.000 100.00
200.00 mA 1.2000 3.0000 6.0000 12.000 30.000 60.000 120.00 200.00
500.00 mA 3.0000 7.5000 15.000 30.000 75.000 150.00 300.00 500.00
1.0000 A 6.0000 15.000 30.000 60.000 150.00 300.00 600.00 1.0000 k
2.0000 A 12.000 30.000 60.000 120.00 300.00 600.00 1.2000 k 2.0000 k
5.0000 A 30.000 75.000 150.00 300.00 750.00 1.5000 k 3.0000 k 5.0000 k
10.000 A 60.000 150.00 300.00 600.00 1.5000 k 3.0000 k 6.0000 k 10.000 k
20.000 A 120.00 300.00 600.00 1.2000 k 3.0000 k 6.0000 k 12.000 k 20.000 k
