SCANNER SAFETY AND LOCAL CONTROLS
Table. 13. MSS Information Linked to Offsheet Indicator Flashing
MSS Summary Display Information (flashing offsheet lamp only)
/scanner 1/mss/sensor manager/job set/alarm condition found
Frame In Break Mode To Clear Press Off Sheet or Scan
/scanner 1/mss/position control/job set/frame controller/what’s wrong status/what’s wrong info
2011-10-06 11:39:33: Stop Switch ON Frame or External Stop Armed Interlock
EFC Stop Armed Digital Input is Open. Check Stop Button on the frame
/scanner 1/mss/sensor manager/job set/alarm condition found
Frame In Off Sheet To Nearest Side Mode To Clear Press Off Sheet. Mode Will Not Clear If condition
still exists
/scanner 1/mss/sensor manager/job set/lumpdetector/current state
Lump Detector is a digital input and should be off. This signal comes in on the FC card. This signal will
trigger the scanner to go to off sheet nearest side mode. Off sheet commands can be used to get the
scanner out of off sheet near side mode, if the lump digital input is off.
2.5.1.5 Radiation Safety Indicators
See Section 2.2 and 2.3 for more information on radiation safety and scanner radiation
safety features.
The Q4000 design implements the radiation shutter status lights on cable and distant end
scanner user panels (see Figure 55), and on each side of the upper and lower heads (see
Figure 56).
