62 | HRGX DVR User Manual
To configure encoding parameters for substream:
1. Go to Menu > Record > Encoding > Substream.
2. Select the camera you want to configure encoding parameters for.
3. Configure the following encoding parameters for substream:
4. To copy these settings to one or more additional cameras, click Copy to open the Copy to
window, select the camera(s) you want to copy the settings to, or click Analog to copy the
settings to all cameras, and then click OK.
5. Click Apply to save your settings.
6.
To restore the current substream settings to the default parameters, click Restore .
•Stream Type Set the stream type to Video or Video & Audio .
•Resolution Set the recording resolution to one of the following settings:
WD1 , 4CIF , 2CIF , CIF , or QCIF .
•Bitrate Type Set the bitrate type to Variable or Constant .
• Video Quality Set the recording video quality. 6 levels configurable.
•Frame Rate Set the recording frame rate.
• Max. Bitrate Mode Set the bit rate mode to General or Customize .
• Max. Bitrate(Kbps) Select or customize the maximum bit rate for recording.
