3.4 Configuration Tips
Introduction
Listed below in Table 3-1 are a few tips that will help you enter the
configuration data more quickly.
Table 3-1 Configuration Tips
Function Tip
Displaying Groups
Use the [SET UP] key to display the Set Up groups. The group
titles are listed in this section in the order that they appear in
the controller.
Displaying
Functions
Use the [FUNCTION] key to display the individual parameters
under each group. The prompts are listed in the order of their
appearance in each group.
Scrolling
To get to a Set Up group prompt more quickly, hold the [SET
UP] key in. To get to a Function prompt more quickly, hold the
[FUNCTION] key in. The display will scroll through the
parameters.
ATTENTION
The prompting scrolls at a rate of 2/3
seconds when the [SET UP] or [FUNCTION] key is held in.
Also, [s] or [t] keys will move Group prompts forward and
backward at a rate twice as fast.
Changing values
quickly
When changing the value of a parameter, you can adjust a
more significant digit in the upper display by holding in one key
[s] or [t] , and pressing the other [s] or [t] at the same time.
The adjustment will move one digit to the left. Press the key
again and you will move one more digit to the left.
Restoring to the
original value
When you change the value or selection of a parameter while
in Set Up mode and decide not to enter it, press the lower
blank key once, the original value or selection will be recalled.
Exiting SET UP
mode
To exit Set Up mode, press the [LOWER DISPLAY] key.
This returns the display to the same state it was in immediately
preceding entry into the Set Up mode.
Timing out from Set
Up mode
If you are in Set Up mode and do not press any keys for one
minute, the controller will time out and revert to the mode and
display that was being used prior to entry into Set Up mode.
Key Error
When a key is pressed and the prompt “KEY ERROR” appears
in the lower display, it will be for one of the following reasons:
• parameter not available
• not in Set Up mode, press [SET UP] key first
• key malfunction, do keyboard test (operation)
