6.2 Minimum and Maximum Range Values
Select the range
values
You should calibrate the controller for the minimum (0%) and maximum
(100%) range values of your particular sensor.
Select the Voltage or Resistance equivalent for 0% and 100% range values
from Table 6-1. Use these values when calibrating your controller.
Table 6-1 Voltage and Resistance Equivalents for 0% and 100% Range Values
Sensor Type PV Input Range Range Values
° F ° C 0% 100%
Thermocouples
B
0 to 3300 –18 to 1816 –0.100 mV 13.769 mV
E
-454 to 1832 –270 to1000 –9.835 mV 76.373 mV
E (low)
-200 to 1100 –129 to593 –6.472 mV 44.455 mV
J
0 to 1600 –18 to871 –0.886 mV 50.060 mV
J (low)
20 to 770 –7 to410 –0.334 mV 22.400 mV
K
0 to 2400 –18 to1816 –0.692 mV 52.952 mV
K (low)
–20 to 1000 –29 to538 –1.114 mV 22.255 mV
NiNiMoly (NNM68)
32 to 2500 0 to1371 0.000 mV 71.330 mV
NiNiMoly (low)
32 to 1260 0 to682 0.000 mV 31.820 mV
NiMo-NiCo (NM90)
32 to 2500 0 to1371 0.000 mV 71.773 mV
NiMo-NiCo (low)
32 to 1260 0 to682 0.000 mV 31.825 mV
Nicrosil Nisil (Nic)
0 to 2372 –18 to1300 –0.461 mV 47.513 mV
R
0 to 3100 –18 to1704 –0.090 mV 20.281 mV
S
0 to 3100 –18 to1704 –0.092 mV 17.998 mV
T
-300 to 700 –184 to371 –5.341 mV 19.097 mV
T (low)
-200 to 500 –129 to260 –4.149 mV 12.574 mV
W5W26
0 to 4200 –18 to2315 –0.234 mV 37.075 mV
W5W26 (low)
0 to 2240 –18 to1227 –0.234 mV 22.283 mV
Honeywell Radiamatic
Type RH
Type RI
0 to 3400
0 to 3200
–18 to1871
–18 to1760
0.00 mV
0.00 mV
57.12 mV
60.08 mV
RTD
(IEC Alpha=0.00385)
100 ohms
100 ohms (low)
200 ohms
500 ohms
-300 to 1200
-300 to 300
-300 to 1200
-300 to 1200
–184 to649
–184 to149
–184 to649
–184 to649
25.18 ohms
25.18 ohms
50.36 ohms
125.90 ohms
274.96 ohms
156.90 ohms
549.92 ohms
1374.80 ohms
Linear
Milliamps
4 to 20 mA*
0 to 20 mA*
4.00 mA
0.00 mA
20.00 mA
20.00 mA
Millivolts
0 to 10 mV*
0 to 50 mV*
0.00 mV
0.00 mV
10.00 mV
50.00 mV
Volts
1 to 5 Volts*
0 to 5 Volts*
0 to 10 Volts*
1.00 Volts
0.00 Volts
0.00 Volts
5.00 Volts
5.00 Volts
10.00 Volts
* not available for FM models
