24 UDC3300 Limit Controller Product Manual 1/01
3.5 Configuration Procedure, Continued
Procedure, continued
Table 3-2 Configuration Procedure, Continued
Step Operation Press Result
4
Select other Function
Parameters
FUNCTION
Successive presses of the [FUNCTION] key will
sequentially display the other function prompts of the
Set Up group you have selected.
Stop at the function prompt that you want to change,
then proceed to the next step.
5
Change the value or
selection
or
These keys will increment or decrement the value or
selection that appears for the function prompt you have
selected.
See “Configuration Tips” for instructions to increase or
decrease value quickly.
Change the value or selection to meet your needs.
If the display flashes, you are trying to make an
unacceptable entry.
6
Enter the value or selection
FUNCTION
or
SET UP
This key selects another Function prompt.
This key selects another Set Up group.
The value or selection you have made will be entered
into memory after another key is pressed.
7
Exit Configuration
LOWER
DISPLAY
This exits configuration mode and returns the controller
to the same state it was in immediately preceding entry
into the Set Up mode. It stores any changes you have
made.
