7.2 Troubleshooting Aids
Overall error
messages
An error message can occur
• at power-up
• during continuous background tests while in normal operation
• when the Status Tests are requested
Table 7-1 lists all the error message prompts that you could see, the reason
for the failure, and under what test group the prompt could appear.
Refer to Tables 7-3 (Power-up), 7-5 (Status), and 7-6 (Background) for the
particular test group indicated.
Table 7-1 Error Message Prompts
Error
Message
(lower
display)
Reason for Failure Test Group Refer to
Table
CAL TEST
Calibration test failure Power-up or
Status
7-3
7-5
CONFTEST
Configuration test failure Power-up or
Status
7-3
7-5
E E FAIL
Unable to write to non-volatile
memory
Background 7-6
FACT CRC
Factory Calibration Cyclic
Redundancy test
Status 7-5
FAILSAFE
Controller in Failsafe Power-up,
Background, or
Status
7-3
7-5
7-6
INP1FAIL
Two consecutive failures of
Input 1 integration
Background 7-6
INP1 RNG
Input 1 Out of Range Background 7-6
PV LIMIT
PV Out of Range Background 7-6
RAM TEST
RAM test failed Power-up or
Status
7-3
7-5
Continued on next page
